CEASEFIRE
- SYSTEMS:
Fire Suppression Systems - ORIGIN:
India
With a 360 degree holistically integrated, globally certified, products & services portfolio, Ceasefire epitomises quality & excellence. For decades now, they've pioneered fire safety in India, through Fire Fighting systems and technologies that are unique to Ceasefire, and built at the very forefront of new-age technology.
For past over 25 years, they have manufactured, tested and sold hundreds of thousands of extinguishers & systems, without a single case of malfunction.
Their products today epitomise quality and performance and have attained global certifications on top quality standards in fire safety including EN3,7-8, EN1866, LPS, MED, PED(CE), ISO & OHSAS from world's best quality agencies including LPCB, BRE Global, British Standards Institute (BSI) & EuroCert.
A Ceasefire product today is sold every 60 seconds and is used on a real life fire emergency to save a life every 5 minutes.
A leading manufacturer of Globally certified fire safety solutions including:
1. Portable & Wheeled Type Fire Extinguishers: ABC Powder, CO2, Water, Foam, Water mist, Clean Agent and Special Agent variants.
2. A full range of Micro Environment & In Panel Fire Suppression Systems.
3. Gas Based Suppression Systems (HFC227ea).
4. Water mist based Suppression Systems.
5. Full range of Water mist and Wet Chemical Based Kitchen Fire Suppression Systems.
6. Water mist based Hydrant Systems.
7. Extensive range of Fire Detection & Alarm Solutions.
FIRE SUPPRESSION SYSTEMS
ORIGIN:
India
info
Ceasefire's range of its state-of-the-art fire suppression systems is designed to detect and extinguish fire automatically without any human intervention. These systems bring in revolutionary fire fighting solutions that combine ground-breaking technology with functional simplicity to keep whats precious, safe.
- HFC227ea (FM 200 gas) Based Total Flooding System.
- Watermist Based Generator Auto Quell System.
- Watermist Based Transformer Auto Quell System.
- Watermist Indoor Auto-Quell System.
- Watermist Twin Fluid System (Swift).
HFC227ea (FM 200 gas) Based Total Flooding System
info
Revolutionary total flooding fire suppression solution based on one of the cleanest extinguishing agent- HFC227ea.
The Ceasefire HFC 227ea flooding system is a suppression system that achieves extensive coverage. This self-activated system uses advanced technology to achieve maximum extinguishing efficiency. When the detectors sense a rise in temperature above normal levels, particles of smoke or a change in the quality of air, they alert the Control Panel. The Control Panel, in turn, activates the System.
HFC 227ea is the worldwide most widely accepted selected clean agent use in new application and as a Halon replacement, (HFC 227 ea CF3 CHFCF3), is safe, clean and electrically non- conductive fire specification agent that protects people’s high value assets in the business operations.
Available in Pre-Engineered and Engineered variations.
Watermist Based Generator Auto Quell System
info
An integrated, micro-environment based system that combines Watermist and clean agent suppression technology.
Ceasefire's Watermist Generator Auto-Quell System is a revolutionary, all-purpose detection and fire suppressant system solution. Ensuring complete annihilation of the fire, the system has a dual approach to firefighting.
First, in the generator area, a network of detection devices, special Watermist nozzles and a connection either to a water tank or water cylinders is installed in the micro-environment. In the event of a fire, the system kicks into action in seconds.
The specially designed nozzles dispense Watermist, made up of microscopic droplets of water (below 70 microns), onto the fire affected area, quickly putting out the flames as well as bringing the temperature down to non-combustion levels.
Watermist Based Transformer Auto Quell System
info
A local application based system that uses Watermist suppression technology to confine the fire in or around the transformer.
The Ceasefire Watermist Auto-Quell System is a revolutionary, all-purpose detection and fire suppressant solution for transformer fires.
The system consists of a network of detection devices, special Watermist nozzles and a connection to a water tank installed in the local environment of the transformer. In the event of a fire, the system is programmed to kick into action in seconds. The specially designed nozzles dispense Watermist, made up of microscopic droplets of water (below 120 microns), onto the fire affected area, quickly putting out the flames as well as bringing the temperature down to non-combustion levels.
Entirely self-activated and requiring no human intervention, this integrated system provides a complete detection and suppression solution for transformer fires, working quickly to save property and lives. What's more, since the Auto-Quell System is Watermist based, it has no long-term effect on the work environment and operations can resume without any time lost.
Watermist Indoor Auto Quell System
info
An integrated application system that adds cutting edge technology to the traditional sprinkler systems.
A network of detection devices, special Watermist nozzles and a connection to a water tank is installed indoors. In the event of a fire, the system kicks into action in seconds.
The specially designed nozzles dispense Watermist , made up of microscopic droplets of water (below 100 microns), onto the fire affected area, quickly putting out the flames as well as bringing the temperature down to non-combustion levels. Entirely self-activated and requiring no human intervention, this integrated system provides a complete detection and suppression solution, working quickly to save property and lives.
What's more, since the Auto-Quell System is Watermist based, it has no long-term effect on the work environment and operations can resume with no time lost.
Watermist Twin Fluid System
info
This Watermist-based low-pressure two-phase flooding system achieves extensive coverage.
Ceasefire SWIFT has been specially designed for commercial enterprises. The USP of the system is that it uses Watermist, which causes no collateral damage, ensuring that business operations are up and running at the earliest. Available in flexible system configuration options, SWIFT provides the most efficient protection for all business premises with the benefit of cost-effectiveness.
Featuring automatic activation, it can even be integrated with electricity shut off valves and relays to trigger the fire alarm.
Atom X Pre-Engineered Retrofittable Fire Suppression System
Product Overview
Understanding the evolving demands of unique infrastructures and businesses, Ceasefire presents the next generaton specialized fire suppression technology. Ceasefire Atom X doesn’t demand any structural change neither consumes the floor space nor leads to down time, as this innovative system is mounted on the ceiling of the space. Designed with smart and sensitive features, it minimizes the possibility of false activation and safeguards the premises. The system is an automated smart network of ceiling mounted agent containers, an array of detection devices and a control panel.
Product Features
Requires Minimal Fittings: A key advantage of the system is that it does not require an extensive network of pipes, fittings and ducts; and the plumbing & mechanical works associated with it.
Cost Effective Solution: Since the system does not require so many fittings, fixtures and plumbing, it works out to be highly cost effective.
Easy to Install: The system is a retro-fittable one and hence can be installed in a running and functional premises without hindering the daily business operations of the place. This is because minimal structural changes are required to be done in the premises to install the system.
Intelligent Detection: The detection module of the system can include devices that are most suitable to address the risks present at the premises.
Consumes Minimal Productive Space: The system being ceiling mounted consumes no floor space. Big boon for business premises where productive floor space is not consumed by the system’s agent containers.
Tamper Proof by Design: Being ceiling mounted, the system also becomes tamper proof as the system is not accessible to everyone.
Inert Gas & CO2 Based Fire Suppression System
The Basic Premise
The idea behind Ceasefire Inert Gas Fire System is to reduce the amount of oxygen present in the area where the fire breaks out. This is important because fires need oxygen in order to spread. Remove this vital element and the fire will be easier to contain. While the oxygen level is lowered, the system does not eliminate oxygen from the space altogether. There is still enough Oxygen present to support proper breathing, as anyone in the immediate area moves along the escape route and exits the room.
What gases are used?
Ceasefire Inert Gas Suppression Systems use the following gases that reduce the concentration of Oxygen in the fire zone to kill fires.
These included:
CF1: CO2 (100%)
CF100: Nitrogen (100%)
CF541: A blend of Nitrogen(50%) + Argon(40%) + C02(10%)
CF01: Argon (100%)
CF55: A mix of Argon(50%) + Nitrogen(50%)
These inert gases are naturally occurring gases. We are surrounded by these gases. These gases reduce concentration of oxygen in the given space and extinguishes fire.
How is the Gas Deployed?
The Ceasefire Gaseous Fire Suppression systems can be configured for unique gas discharge options. Typically class "C" electrical fires require a minimum concentration while class "B" flammable liquid fires require a higher concentration or lowering of oxygen levels to put the fire out. Settling on the right approach depends on the type of environment in which the system will be used.
How does the system works?
The air we breathe has approximately 21% of Oxygen. Oxygen is the key factor in sustaining a fire and the key factor in keep us alive too! By removing the oxygen, we will certainly extinguish a fire, but that comes with obvious problems. How do we sustain life at the same time? Fires need more than 16% Oxygen to combust. Anything below this level of oxygen will not be enough for a fire to sustain combustion.
Kitchen Fire Suppression Systems
Ceasefire’s LPCB certified Kitchen Fire Suppression Systems are available in Water Mist based & Wet Chemical Based variations.
Types of kitchen suppression systems:
Water mist based kitchen suppression system (Enviro Series).
Wet chemical based Kitchen Suppression System (Ultra Series).
Water Mist Based Kitchen Suppression System
Ceasefire’s Watermist based suppression system comes with the advanced fire detection technology based on the Heat Sensing Tube. This tube gives the entire kitchen hood a uniform protection compared to the point-based detection system used in conventional methods of kitchen fire suppression. Furthermore, the state-of-the-art discharge nozzles are designed to knock-off fire arising from any kind of cooking, be it deep-frying, grilling, shallow- frying, roasting, sautéing etc. These technologically advanced nozzles ensure enhanced throw and their strategic positioning rules out any possibility of a blind spot.
Enviro Series Kitchen Suppression System - M / Pre-Engineered
Trigged by smoke , the first sign of a fire ; and a corresponding rise in temperature, this powerful, automated firefighting system is fully equipped to douse the flames, before they spiral out of control. The USP of the system is that it's a Watermist system, which causes no collateral damage, ensuring the kitchen is up and running at the earliest. The Ceasefire Design Cell has created 7 pre-fabricated variants of the system, which can be installed in kitchens of different sizes. They are designed with utmost precision to international quality standards, and come with complete sets of accessories to fulfill all the requirements of a fire-prone microenviroment.
Enviro Series Kitchen Suppression System / Engineered
While other extinguishing system use chemicals to put out fires, these chemicals completely ruin your kitchen. Ceasefire's Enviro Series Kitchen Suppression System has been specially designed for commercial kitchens.The USP of the system is that it's a Watermist system, which causes no collateral damage, ensuring the kitchen is up and running at the earliest.
Available in flexible system configuration options, the Kitchen Suppression System provides the most efficient protection for all cooking applications and facilities, with the benefit of cost-effectiveness. Featuring automatic activation, it can even be integrated with gas shut off valves and relays to trigger the fire alarm.
Wet Chemical Based Kitchen Suppression System
Ceasefire’s Wet chemical based Kitchen Suppression System relies on the powerful extinguishing properties of a foam agent that is developed with an optimized biological tolerance. This is possible as the agent is 90% water and 10% foam based chemical. The 99% biodegradable extinguishing agent of wet-chemical based kitchen suppression system forms a foam blanket on top of the fire, thereby eliminating entry of oxygen and killing fire instantly. At, the same time it contains 90% water and hence has a tremendous cooling effect that ensures there is no re-ignition of fire. As the agent is a wet chemical – foam, there is no flooding related collateral damage; moreover the agent residue can be used as a cleaning medium for the cook tops and equipments.
Ceasefire Ultra Series - M / Pre-Engineered
The Ultra Kitchen Suppression system - M from Ceasefire is designed as an economical yet effective firefighting solution. The system uses specially formulated, non-corrosive wet chemical extinguishing agent and specially designed heat-sensing pneumatic polymer tube to combat even the worst kitchen fires. The Ceasefire Design Cell has created 6 pre-fabricated variants of the system, which can be installed in kitchen of different sizes. They are designed with utmost precision to international quality standards,and come with complete sets of accessories to fulfil all the requirements of a fire-prone microenviroment.
Ceasefire Ultra Series / Engineered
The system’s most prominent feature - a specially designed heat-sensitive pneumatic polymer tube is installed to run unobtrusively throughout the area at risk. When a fire breaks out, the heat-sensitive tube detects the rise in temperature and punctures at that point. This triggers the system which releases the Wet Chemical extinguishing agent through a separate discharge line and expels it through state-of-the-art, nozzles. Dousing the flames by smothering them with the spray of specialized foam. And bringing down the temperature to below combustion levels.
Micro Environment
Fire Suppression
Ceasefire Micro Environment Fire Suppression Systems are designed for special application areas like Electrical panels, Server racks or any other enclosed micro environment that is vulnerable to the risk of fire. These systems are equipped with most advanced fire detection & activation technology that makes them capable of split-second detection and activation. The systems are designed not just to quell fires, but to truly protect the expensive equipments in the area.
Variations/Types of micro environment fire suppression systems:
1. Ceasefire Quick Response System (CQRS).
2. Ceasefire Server Quick Response System (SQRS).
3. Ceasefire Mini.
Ceasefire Quick Response System (CQRS)
In-Panel tube based fire suppression system
Electrical Short Circuit is the primary reason for big, fatal fires in most premises today. In such fires these short circuits occur mostly inside the electrical panels as this is where high voltage lines terminate. In seconds, what is a small spark turns into a flame and then a fiery blaze in a matter of few minutes. Lives are lost and property is gutted.
Presenting Ceasefire's Quick Response System(CQRS) that is designed to fight fires that occur in the enclosed space of electric panels. The CQRS system's split second detection and activation ensures that the fires are killed in the nascent stage inside the most vulnerable spaces i.e. the electrical panels.
Key Features:
1. Certified by LBCB for LPS1666 Standard certification for 2 & 4 Kg Direct HFC227ea and HFC 236fa gas variants.
2. CQRS operates automatically and requires no human intervention. The system is ready 24x7 to fight fire.
3. Simple design for easy functionality.
4. Entirely self-contained and does not require any power supply.
Ceasefire Server Quick Response System (SQRS)
The world's only macro environment protection system that is also available in the comfort of a micro environment of a server system, the Ceasefire SQRS is the only product that truly protects your highly expensive data servers against fire.
Servers are at the heart of data centers and large organisations. Not just for these companies but for hundreds of their clients' businesses. Keeping this in mind, the Ceasefire SQRS has been specifically built to the specifications of a server rack. Which means it concentrates on protecting the server itself, rather than the macro environment around it.
It is designed to protect the server against damages due to fire and not just to stop the fire. Power of this system is in its speed of detection and activation which does not allow fire the time to grow and damage anything.
The system is installed within the micro environment of a server rack. When the detectors sense a rise in temperature above normal levels, or particles of smoke or a change in the quality of air in the contained server space, the detectors activate the system and the extinguishing agent (HFC 227ea) is discharged. As it activates, a hooter goes off, warning personnel about the fire.
All components of this system including the detectors, controls, extinguishing agent cylinders and alarm devices are packed together as one modular unit.
For high air flow server racks the system comes with a Highly Sensitive Smoke detection option. The optional IP Module gives the user the power to monitor the health of the system through web on a computer or a smart phone and receive email alerts and alarms in case of emergencies.
CF 3000 Watermist Hydrant System
A self-contained, standalone firefighter, suitable for locations with no ready supply of compressed air and water.
Powered by revolutionary Watermist technology, CF 3000 maximizes the firefighting and cooling properties of water, and then increases it manifold. It’s highly dependable and being a standalone firefighter, you don’t need to worry about issues like malfunctioning pipelines and wear and tear on parts that affect commercially available hydrants. What’s more, while other hydrants run dry and other fire extinguishers are exhausted before putting out all the flames, CF 3000 continue the fight against fire.
Featuring the same potent firefighting power as conventional hydrants with much more efficient usage of water, CF 3000 uses just 60 litres of water where a normal hydrant would needs thousands of gallons to achieve the same results. It also features an AFFF Foam additive option for increased extinguishing power.
Being a self-contained, standalone firefighting device, CF 3000 is suitable for locations with no ready supply of compressed air and water. This easy-to-use system features an in-built pressure container, water storage unit and an optional foam supply unit. In an emergency, all you need to do is pull out the long hose, activate the device and instantly you’ll be armed with CF 3000’s immense firefighting power.
In other words, there is virtually no limit to its fire suppression power.
Special Fire Fighting Systems
Types of equipment variants that can be attached to an existing extinguishing system:
1. Ceasefire Lance Pro.
2. Ceasefire Morph.
Ceasefire Lance Pro
Hammer Drill Equipped Watermist Based Fire Fighting System.
Ceasefire Lancepro is a revolutionary fire fighting system that comes to address some of the biggest challenges faced by anyone fighting a blaze in a building complex. Lancepro can also be used directly in case of open fire, whilst maintain a safe distance from the blaze and protecting the goods from collateral damage.
The innovative Ceasefire Lancepro uses Watermist technology enabling it to be used safely on all types of fires including electrical fires. Water in mist form also increases the surface area of water many times over facilitating heat absorption and taking the firefighting power manifold by rapidly bringing down the temperature to below combustible levels and cutting off the oxygen supply.
Having a drill machine along in the Lancepro kit makes it convenient for the fire fighter to douse off the fire in an enclosed area without physically coming in contact with it. A small orifice is all you need to ensure the security of the fire fighter who can quench the fire without actually entering the enclosed space. The drill comes with two bits – one for drilling in concrete surface and another for metal surface drilling. Once the opening is made by the drill unit of Lancepro the watermist gun is inserted through the opening and watermist is discharged. The two types of guns specialize in administering watermist into the fire zone from a horizontal (from the wall) and vertical (from the roof) angle, respectively.
Ceasefire Morph
Ceasefire has once again shown how technology can be used to make a difference and considering some of these key challenges faced by fire fighters, Ceasefire brings to you Ceasefire Morph.
A range of advanced nozzle guns that, upon being attached to an existing hydrant system or fire truck, converts water into the revolutionary extinguishing agent, Water-mist. Multiplying the power of fire truck or water hydrant and allowing them to take on large fires with ease.
Ceasefire Morph converts the water into Watermist making it absolutely safe to use on energized equipment's and above all else, human lives. Watermist also increases the coverage area of water to fight fires many times over, taking the firefighting power of the fire engine or hydrant system many notches higher. Rapidly bringing down the temperature to below combustible levels, and cutting off the oxygen supply.
Fire Extinguishers
Ceasefire is India's most trusted manufacturer on an extensive range of fire extinguishers ranging from ABC Dry Powder Fire Extinguishers, Clean Agent based Fire Extinguishers, Carbon Dioxide Based Fire Extinguishers, Water Based Fire Extinguishers, Watermist Based Fire Extinguishers, Mechanical Foam (AFFF) Fire Extinguishers, Ceiling Mounted Modular Suppression Systems & Specialized Fire Extinguishers.
Types/Range of extinguishers for various applications:
1. Home & Car Range.
2. Core Range.
3. Special Application Range.
4. Modular Suppression System.
5. Watermist Based Fire Extinguisher.
